1
Layout the Liner
Layout the sections of liner to be seamed. Overlap ends 6" - 12".
2
Clean the Seam Area
Lift the top liner. Use gasoline and thoroughly clean the seam area.Warning: Use in a well-ventilated area.
3
Mark the Seam Area
With the top liner down, use a crayon or lightly score with scissors the seam area on the bottom liner. Raise the top liner for priming.
4
Prime the Seam Area
Prime both liners. On the bottom liner, prime 1/4" above the mark, approximately 6" - 8" wide. Prime a matching area on the top liner.
5
Apply 3" Double Stick
Apply 3" double sided tape to the bottom liner, pressure rolling as you go to eliminate air bubbles or wrinkles.
6
Smooth the Seam
With the double stick paper still on, replace the top liner and pressure roll the seam.
7
Seal the Seam
Slit the tape in the center. Overlap liners and carefully remove the paper, pulling at a 45 degree angle, one side at a time.Warning: Take your time - proper technique prevents air pockets.
8
Apply 6" Single Stick
Prime an area 6" wide over the exposed edge of the seam. Apply 6" tape over primer.
9
Roll and Seal
Thoroughly pressure roll the 6" tape and generously apply lap sealant along both edges.
10
Allow to Dry
Allow the seam to dry thoroughly before contact with water.Warning: Drying time varies - when in doubt, wait longer.

PolyGuard PVC Pond Liner

PolyGuard PVC 20-Mil

Pond Liner Calculator

Find the perfect PVC liner size for your pond

PolyGuard PVC 20-Mil Liners

Budget-friendly and lightweight. Easy to handle and install. Perfect for smaller ponds, water gardens, and DIY projects.

Loading products
ft
ft
ft
ft
ft
ft
ft
ft
Your Pond Calculations
Surface Area
0
sq ft
Water Volume
0
gallons
Liner Size
0×0
ft
Max Koi
0
fish
Min Pump
0
GPH
Acre Feet
0


When building your water feature, PVC liner is a cost efficient choice and has a great range of flexibility when needed. The standard warranty is 5 years for PVC liner,  however,  extended sun exposure may cause deterioration. Extend the life of your pond liner by covering the liner above water level.

20 MIL PVC KOI POND LINER
PREMIUM LINER FOR KOI PONDS, WATER GARDENS AND WATERFALLS


Pond Liner is the foundation for any Koi pond, water garden or waterfall. When building your water feature PVC liner is a cost efficient choice and has a great range of flexibility when needed.


- Adapts readily to pond and pondless waterfalls
- Attaches easily to waterfalls, weirs and skimmers
- Certified fish and wildlife safe
- 5 year warranty*



*Don't forget to extend the life of your liner by adding Underlayment!
